Model

Emission

Color

Forward Voltage

IF=750mA

Wavelength/CCT

IF=750mA

Luminous Flux

IF=750mA

WSD-HP3A140R90-02

Red

2.2~2.8V

620~630nm

80~100Lm

WSD-HP3A140Y90-02

Yellow

2.2~2.8V

585~595nm

80~100Lm

WSD-HP3A140B45-02

Blue

3.2~3.8V

460~470nm

40~50Lm

WSD-HP3A140G120-02

Green

3.2~3.8V

515~525nm

100~140Lm

WSD-HP3A140W220-04

Warm White

3.2~3.8V

2700~3500K

200~240Lm

WSD-HP3A140W220-05

Pure White

3.2~3.8V

4000~4500K

200~240Lm

WSD-HP3A140W220-06

Cool White

3.2~3.8V

6000~7000K

200~240Lm

Other Spec

Dimension

14.6X8X5.3mm

50% Power Angle

140deg

Power Dissipation

3W

Forward Current

750mA

Peak Forward Current

2250mA

Reverse Voltage

5V

Electrostatic Discharge

2000~3000V

Operating Temperature

-20~80℃

Storage Temperature

-40~85℃

Soldering Temperature

Max. 260℃ for 5 sec Max.

Notes: specifications are for reference only, specification subjected to change without prior notice.
