Model

Emission

Color

Forward Voltage

IF=750mA

Wavelength/CCT

IF=750mA

Luminous Flux

IF=750mA

WSD-5050A120W550-01

Warm White

6.0~6.8V

2700~3500K

500~600Lm

WSD-5050A120W550-02

Pure White

6.0~6.8V

4000~4500K

500~600Lm

WSD-5050A120W550-03

Cool White

6.0~6.8V

6000~7000K

500~600Lm

Other Spec

Dimension

5.0X5.0X0.9mm

50% Power Angle

120deg

Power Dissipation

5W

Forward Current

750mA

Peak Forward Current

2250mA

Reverse Voltage

5V

Electrostatic Discharge

2000~3000V

Operating Temperature

-20~80℃

Storage Temperature

-40~85℃

Soldering Temperature

Max. 260℃ for 5 sec Max.

Notes: specifications are for reference only, specification subjected to change without prior notice.
