Model

Emission

Color

Forward Voltage

IF=450mA

Wavelength/CCT

IF=450mA

Luminous Flux

IF=450mA

WSD-5050A120W330-01

Warm White

6.0~6.8V

2700~3500K

300~360Lm

WSD-5050A120W330-02

Pure White

6.0~6.8V

4000~4500K

300~360Lm

WSD-5050A120W330-03

Cool White

6.0~6.8V

6000~7000K

300~360Lm

Other Spec

Dimension

5.0X5.0X0.9mm

50% Power Angle

120deg

Power Dissipation

3W

Forward Current

450mA

Peak Forward Current

1350mA

Reverse Voltage

5V

Electrostatic Discharge

2000~3000V

Operating Temperature

-20~80℃

Storage Temperature

-40~85℃

Soldering Temperature

Max. 260℃ for 5 sec Max.

Notes: specifications are for reference only, specification subjected to change without prior notice.
