Model

Emission

Color

Forward Voltage

IF=350mA

Wavelength

IF=350mA

Luminous Flux

IF=350mA

WSD-HP1A140IR15-02

Infrared

2.0~2.8V

840~850nm

10~20Lm

WSD-HP1A140IR25-02

Infrared

2.0~2.8V

930~940nm

20~30Lm

Other Spec

Dimension

14.6X8X5.3mm

50% Power Angle

140deg

Power Dissipation

1W

Forward Current

350mA

Peak Forward Current

1050mA

Reverse Voltage

5V

Electrostatic Discharge

2000~3000V

Operating Temperature

-20~80℃

Storage Temperature

-40~85℃

Soldering Temperature

Max. 260℃ for 5 sec Max.

Notes: specifications are for reference only, specification subjected to change without prior notice.
