Model

Emission

Color

Forward Voltage

IF=350mA

Wavelength/CCT

IF=350mA

Luminous Flux

IF=350mA

WSD-HP1A140R45-02

Red

2.0~2.8V

620~630nm

40~50Lm

WSD-HP1A140Y45-02

Yellow

2.0~2.8V

585~595nm

40~50Lm

WSD-HP1A140B25-02

Blue

3.0~3.8V

460~470nm

20~30Lm

WSD-HP1A140G75-02

Green

3.0~3.8V

515~525nm

70~80Lm

WSD-HP1A140W110-04

Warm White

3.0~3.8V

2700~3500K

100~120Lm

WSD-HP1A140W110-05

Pure White

3.0~3.8V

4000~4500K

100~120Lm

WSD-HP1A140W110-06

Cool White

3.0~3.8V

6000~7000K

100~120Lm

Other Spec

Dimension

14.6X8X5.3mm

50% Power Angle

140deg

Power Dissipation

1W

Forward Current

350mA

Peak Forward Current

1050mA

Reverse Voltage

5V

Electrostatic Discharge

2000~3000V

Operating Temperature

-20~80℃

Storage Temperature

-40~85℃

Soldering Temperature

Max. 260℃ for 5 sec Max.

Notes: specifications are for reference only, specification subjected to change without prior notice.
