Model

Emission

Color

Forward Voltage

IF=750mA

Wavelength/CCT

IF=750mA

Luminous Flux

IF=750mA

WSD-3535A120W220-01

Warm White

3.0~3.8V

2700~3500K

200~240Lm

WSD-3535A120W220-02

Pure White

3.0~3.8V

4000~4500K

200~240Lm

WSD-3535A120W220-03

Cool White

3.0~3.8V

6000~7000K

200~240Lm

Other Spec

Dimension

3.5X3.5X2.0mm

50% Power Angle

120deg

Power Dissipation

3W

Forward Current

750mA

Peak Forward Current

2250mA

Reverse Voltage

5V

Electrostatic Discharge

2000~3000V

Operating Temperature

-20~80℃

Storage Temperature

-40~85℃

Soldering Temperature

Max. 260℃ for 5 sec Max.

Notes: specifications are for reference only, specification subjected to change without prior notice.
