Model

Emission

Color

Forward Voltage

IF=20mA

Wavelength/CCT

IF=20mA

Luminous Intensity

IF=20mA

WSD-D5A45R3500-01

Red

1.8~2.2V

620~630nm

3000~4000MCD

WSD-D5A45Y3500-01

Yellow

1.8~2.2V

585~595nm

3000~4000MCD

WSD-D5A45B3500-01

Blue

3.0~3.4V

460~470nm

3000~4000MCD

WSD-D5A45G6500-01

Green

3.0~3.4V

515~525nm

6000~7000MCD

WSD-D5A45W7500-01

Warm White

3.0~3.4V

2700~3500K

7000~8000MCD

WSD-D5A45W7500-02

Pure White

3.0~3.4V

4000~4500K

7000~8000MCD

WSD-D5A45W7500-03

Cool White

3.0~3.4V

6000~7000K

7000~8000MCD

Other Spec

Dimension

5mm

50% Power Angle

45deg

Power Dissipation

60mW

Forward Current

20mA

Peak Forward Current

100mA

Reverse Voltage

5V

Electrostatic Discharge

2000~3000V

Operating Temperature

-20~80℃

Storage Temperature

-40~85℃

Soldering Temperature

Max. 260℃ for 5 sec Max.

Soldering Distance

>5mm

Notes: specifications are for reference only, specification subjected to change without prior notice.
