Model

Emission

Color

Forward Voltage

IF=750mA

Wavelength/CCT

IF=750mA

Luminous Flux

IF=750mA

WSD-HP5A140R150-01

Red

4.5~5.5V

620~630nm

140~160Lm

WSD-HP5A140Y150-01

Yellow

4.5~5.5V

585~595nm

140~160Lm

WSD-HP5A140B70-01

Blue

6.5~7.5V

460~470nm

60~80Lm

WSD-HP5A140G240-01

Green

6.5~7.5V

515~525nm

200~280Lm

WSD-HP5A140W320-01

Warm White

6.5~7.5V

2700~3500K

280~360Lm

WSD-HP5A140W320-02

Pure White

6.5~7.5V

4000~4500K

280~360Lm

WSD-HP5A140W320-03

Cool White

6.5~7.5V

6000~7000K

280~360Lm

Other Spec

Dimension

20X21X7.4mm

50% Power Angle

140deg

Power Dissipation

5W

Forward Current

750mA

Peak Forward Current

2250mA

Reverse Voltage

5V

Electrostatic Discharge

2000~3000V

Operating Temperature

-20~80℃

Storage Temperature

-40~85℃

Soldering Temperature

Max. 260℃ for 5 sec Max.

Notes: specifications are for reference only, specification subjected to change without prior notice.
