Model

Emission

Color

Forward Voltage

IF=60mA

Wavelength/CCT

IF=60mA

Luminous Flux

IF=60mA

WSD-2835A120W25-01

Warm White

3.0~3.4V

2700~3500K

22~28Lm

WSD-2835A120W25-02

Pure White

3.0~3.4V

4000~4500K

22~28Lm

WSD-2835A120W25-03

Cool White

3.0~3.4V

6000~7000K

22~28Lm

Other Spec

Dimension

2.8X3.5X0.8mm

50% Power Angle

120deg

Power Dissipation

0.2W

Forward Current

60mA

Peak Forward Current

180mA

Reverse Voltage

5V

Electrostatic Discharge

2000~3000V

Operating Temperature

-20~80℃

Storage Temperature

-40~85℃

Soldering Temperature

Max. 260℃ for 5 sec Max.

Notes: specifications are for reference only, specification subjected to change without prior notice.
