Model

Emission

Color

Forward Voltage

IF=20mA

Wavelength/CCT

IF=20mA

Luminous Intensity

IF=20mA

WSD-P3A90R800-01

Red

1.8~2.2V

620~630nm

600~1000MCD

WSD-P3A90Y800-01

Yellow

1.8~2.2V

585~595nm

600~1000MCD

WSD-P3A90B1400-01

Blue

3.0~3.4V

460~470nm

1200~1600MCD

WSD-P3A90G3500-01

Green

3.0~3.4V

515~525nm

3000~4000MCD

WSD-P3A90W3500-01

Warm White

3.0~3.4V

2700~3500K

3000~4000MCD

WSD-P3A90W3500-02

Pure White

3.0~3.4V

4000~4500K

3000~4000MCD

WSD-P3A90W3500-03

Cool White

3.0~3.4V

6000~7000K

3000~4000MCD

Other Spec

Dimension

3mm

50% Power Angle

90deg

Power Dissipation

60mW

Forward Current

20mA

Peak Forward Current

100mA

Reverse Voltage

5V

Electrostatic Discharge

2000~3000V

Operating Temperature

-20~80℃

Storage Temperature

-40~85℃

Soldering Temperature

Max. 260℃ for 5 sec Max.

Soldering Distance

>5mm

Notes: specifications are for reference only, specification subjected to change without prior notice.
